Whirlpool Range Surface Element W11120791 4381772 570199

Range Surface Element – Whirlpool

Whirlpool Range Surface Element W11120791 4381772 570199 This range surface element creates ignition or controlled heat for surface cooking, baking, broiling, or another heating function. It is intended as a model-specific replacement for the service part listed below. Confirm the complete appliance model and serial number before ordering. Part-Specific Details OEM Whirlpool W11120791 W10894483 Surface Element Control Infinite Switch Part Number W11120791 replaces 4381772, 570199, 703650, 7403P402-60, W10894483, WP7403P402-60, Y04100359, Y04100360, Y04100361, Y04100426, Y04100429, Y04100502 Product Specifications Brand: Whirlpool Primary SKU: W11120791 Product type: Range Surface Element Application: model-specific range repair Verify fuel or voltage application, wattage where marked, connector style, mounting position, dimensions, and burner location Inspect wiring, gas ports, ground path, terminals, and heat shields Replaces / Cross-Reference Part Numbers W11120791, 4381772, 570199, 703650, 7403P402-60, W10894483, WP7403P402-60, Y04100359, Y04100360, Y04100361, Y04100426, Y04100429, Y04100502 Cross-reference numbers can identify earlier revisions, distributor references, or approved service replacements. Compatibility can vary by production date and model revision. Symptoms of Failure Burner or element will not heat or ignite delayed or intermittent ignition uneven heat weak spark or glow visible break, hot spot, or cracked ceramic Installation Instructions Disconnect electrical power, shut off gas when applicable, and allow the appliance to cool. Document wiring and burner orientation, transfer connectors carefully, secure the replacement without stressing ceramic or terminals, reinstall shields, restore gas and leak-test disturbed fittings, then restore power and test at a low setting. Compatibility and Safety Confirm fit using the appliance rating label and Whirlpool-family parts diagram. Disconnect power and shut off water or gas when applicable, wear suitable protective equipment, preserve all shields and guards, and use a qualified technician for gas-system or unfamiliar electrical repairs.

Compatible Part Numbers

• W11120791
• 4381772
• 570199
• 703650
• 7403P402-60
• W10894483
• WP7403P402-60
• Y04100359
• Y04100360
• Y04100361
• Y04100426
• Y04100429
• Y04100502

Key Features

• Product type: Range Surface Element
• SKU / MPN: W11120791

Fixes These Symptoms

• Burner or element will not heat or ignite
• delayed or intermittent ignition
• uneven heat
• weak spark or glow
• visible break
• hot spot
• or cracked ceramic

Compatible Brands

• Whirlpool
• Maytag
• KitchenAid
• Amana
• Jenn-Air
• Roper
• Kenmore

Always verify your complete appliance model number before ordering.

Installation Guidance

Disconnect electrical power, shut off gas when applicable, and allow the appliance to cool. Document wiring and burner orientation, transfer connectors carefully, secure the replacement without stressing ceramic or terminals, reinstall shields, restore gas and leak-test disturbed fittings, then restore power and test at a low setting.
