Whirlpool Oven Thermal Fuse W11025102

Oven Thermal Fuse – Whirlpool

Whirlpool Oven Thermal Fuse W11025102 This oven thermal fuse monitors or controls temperature, power, timing, or a safety circuit within the appliance. It is intended as a model-specific replacement for the service part listed below. Confirm the complete appliance model and serial number before ordering. Part-Specific Details OEM Whirlpool W11025102 Oven Thermal Fuse Cross Reference Information Part Number W11025102 replaces AP6037385, PS11770208, W10794084. Models Cross-reference: Manufacturer Model Number KitchenAid KODC304EBL00 KitchenAid KODC304ESS00 KitchenAid KODC304EWH00 KitchenAid KOSC504ESS00 Whirlpool WOD51ES4EB00 Whirlpool WOD51ES4ES00 Whirlpool WOD51ES4EW00 Whirlpool WOS11EM4EB00 Whirlpool WOS11EM4EW00 Whirlpool WOS51ES4EB00 Whirlpool WOS51ES4ES00 Whirlpool WOS51ES4EW00 KitchenAid KODC304EBL01 KitchenAid KODC304ESS01 KitchenAid KODC304EWH01 KitchenAid KOSC504ESS01 Whirlpool WOD51ES4EB01 Whirlpool WOD51ES4ES01 Whirlpool WOD51ES4EW01 Whirlpool WOS11EM4EB01 Whirlpool WOS11EM4EW01 Whirlpool WOS51ES4EB01 Whirlpool WOS51ES4ES01 Whirlpool WOS51ES4EW01 Product Specifications Brand: Whirlpool Primary SKU: W11025102 Product type: Oven Thermal Fuse Application: model-specific oven repair Verify electrical rating, connector layout, mounting style, control position, and revision Compare every terminal marking and wire location with the original Replaces / Cross-Reference Part Numbers W11025102 Cross-reference numbers can identify earlier revisions, distributor references, or approved service replacements. Compatibility can vary by production date and model revision. Symptoms of Failure No heat or incorrect temperature intermittent operation control will not respond appliance shuts down unexpectedly fault code or open safety circuit Installation Instructions Disconnect power at the breaker. Photograph and label all wire positions, access the control area, transfer connectors one at a time without pulling on wires, secure the replacement and any sensor routing exactly as designed, reinstall covers, restore power, and perform the applicable functional test. Compatibility and Safety Confirm fit using the appliance rating label and Whirlpool-family parts diagram. Disconnect power and shut off water or gas when applicable, wear suitable protective equipment, preserve all shields and guards, and use a qualified technician for gas-system work, or unfamiliar electrical repairs.

Compatible Part Numbers

• W11025102

Key Features

• Product type: Oven Thermal Fuse
• SKU / MPN: W11025102

Fixes These Symptoms

• No heat or incorrect temperature
• intermittent operation
• control will not respond
• appliance shuts down unexpectedly
• fault code or open safety circuit

Compatible Brands

• Whirlpool

Always verify your complete appliance model number before ordering.

Installation Guidance

Disconnect power at the breaker. Photograph and label all wire positions, access the control area, transfer connectors one at a time without pulling on wires, secure the replacement and any sensor routing exactly as designed, reinstall covers, restore power, and perform the applicable functional test.
